JDSU 100G速率IQ調(diào)制器PM-QPSK 單端32 Gbaud OIF通信協(xié)議 2202/2201/2200
The Lumentum 100G PM-QPSK modulator is designed according to the widely
accepted OIF 100GE Tx implementation agreement.
It supports the dual polarization-QPSK modulation scheme, with each of four
parallel MZI’s running at speeds of up to 32 Gbaud.
The chip design features low insertion loss (with very small polarization dependent loss)
as well as a high bandwidth with quasi-linear electro-optic roll-off.
Features
100 Gbps generated from four 25 Gbaud signals (polarization multiplexed 2*50G QPSK, plus FEC)
Single ended
Low insertion loss
Fully integrated with polarization combiner
Designed to OIF implementation agreement
Leading transmission performance
Low drive voltage
Low skew
Applications
100G metro to ultra-long haul transmission with highest spectral efficiency
DWDM over 10G infrastructure (with coherent detection)
100G transponders and linecards
Other modulation formats
Compliance
Qualified to GR-468
>
